RGC-720 Series Hydraulic Thermoforming Machine

Short Description:

RGC series hydraulic thermoforming machine ishigh speed, high productivity,lower noiseadvantage. lt’s sheet feeding-sheet heattreatment-streching forming-cutting edge,asingle fully automatic complete production line. ltis suitable to use PP, PE,PS, PET,ABS and otherplastic sheet to produce drinking cups, juice cups,bowl, tray & food storage boxes and so on.


Product Detail

Product Tags

FUNCTION AND FEATURE

RGC-720 fully automatic hydraulic cup thermoforming machine is high speed, high productivity. sheet feeding-sheet heat treatment-streching forming-cutting edge, a single fully automatic complete production line.

It is suitable to use PP, PE. PS. PVC. PET ABS and other plastic sheet to produce drinking cups. jelly cups, milk cups &food storage boxes. lt can work semi-automatic and full-automatic. It works stable, low noise, reliable to make sure perfect forming products.

PRODUCT FEATURES

1.Servo driving system or hydraulic system offer more smoothly running , easy be operated and maintained.
2.Four column structure guarantee high precision plane accuracy of the running mould sets.
3. Servo motor drive sheet sending and plug assist device , offer high precision running : easy be controlled.
4.China or Germany heater , high heating efficiency , lower power , long life span.
5.PLC with touch screen control system , easy be operated.

PARAMETERS

Model No. Sheet thickness
(mm)
Sheet width
(mm)
Mold forming area
(mm)
Max forming depth
(mm)
Max No-load speed
(cycle/min)
Total power
(kW)
Motor power
(kW)
Power supply Machine total weight
(T)
Dimension
(m)
Servo stretching
(kW)
RGC-720 0.3-2.5 600-730 720X350 140 ≤35 100 11 380V/50HZ 5 3.7X1.6X2.6 7.5

PRODUCTS SAMPLES

RGC-730-7
1
2
3
4
5

Production Process

6

Cooperation Brands

partner_03

FAQ

Q1: Are you a factory or trading company?

A1: We are a factory, and we export our machines to more than 20 countries since 2001.

Q2: How long is the warranty period?

A2: The machine have one year guarantee time and electricl parts for 6 months.

Q3: How to install the machine?

A3: We will send technician to your factory for one week free installment the machine, and training your workers to use it. You pay all related costs, including visa charge, double-way tickets, hotel, meals etc.

Q4:If we are totally new in this area and worry can not find the profession engineer in the local market?

A4: We can help to find the profession engineer from our domestic market. You can hire him for a short time until you have person that can run the machine well. And you just make a deal with the engineer directly.

Q5: Is there other value-add service?

A5: We can offer you some professional suggestions about the production experience,for example: we can offer some formula upon some expecial product like high clear PP cup etc.
