RGC-730S Fully Automatic Cup Thermoforming Machine

Short Description:

RGC-730 fully automatic hydraulic cup thermoforming machine is high speed, high productivity. sheet feeding-sheet heat treatment-streching forming-cutting edge, a single fully automatic complete production line.
It is suitable to use PP, PE. PS. PVC. PET ABS and other plastic sheet to produce drinking cups. jelly cups, milk cups &food storage boxes. lt can work semi-automatic and full-automatic. It works stable, low noise, reliable to make sure perfect forming products.

Send email to us

Product Detail

Product Tags

FUNCTION AND FEATURE

It is suitable to use PP, PE. PS. PVC. PET ABS and other plastic sheet to produce drinking cups. jelly cups, milk cups &food storage boxes. lt can work semi-automatic and full-automatic. It works stable, low noise, reliable to make sure perfect forming products.

PRODUCT FEATURES

1. Servo driving system or hydraulic system offer more smoothly running, easy be operated and maintained.
2. Four column structure guarantee high precision plane accuracy of the running mould sets.
3. Servo motor drive sheet sending and plug assist device, offer high precision running: easy be controlled.
4. China or Germany heater, high heating efficiency, lower power, long life span.
5. PLC with touch screen control system, easy be operated.

PARAMETERS

Model No.	Sheet thickness (mm)	Sheet width (mm)	Max. forming area (mm)	Max.forming depth (mm)	Work speed (shot/min)	Heat rated power (KW)	Motor power	Total weight (Ton)	Dimension (m)
RGC-730	0.25-2.5	600-730	420*720	180	≤35	130	11	6	4.31.62.8
RGC-730A	0.25-2.5	600-730	420*720	230	≤35	150	15	6.5	4.71.63.1

PRODUCTS SAMPLES

Cooperation Brands

SERVICE

1. Clear and clear product warranty regulations to ensure the use of your products. And an efficient and responsive system to handle warranty claims and related issues.
2. We provide technical support services to help you install, use and maintain your products. Help you solve problems through video guides, user manuals, or real-time online communication.
3. Personalized after-sales service, after you purchase the product we will continue to understand your use. Get feedback on usage through surveys or follow-up phone calls. Your feedback will be our direction of continuous improvement.

We will always take your needs and valuable comments as our direction of continuous development, dedicated to provide you with better products and services.
